| Keyboard: |
88 note fully-weighted hammer-action with velocity sensitive keys
(Fatar TP/100LR) |
| Display: |
2×20 character LCD w/ front-panel contrast adjust |
| Polyphony: |
128 Voice Polyphony, dynamically allocated |
| Multitimbral: |
16 parts (one per MIDI channel) |
| Quick Split/Layer: |
Easy access with adjustable relative volume (up to 4 zones) |
| Factory Programs: |
256 stunning factory Programs featuring the all new German Grand Piano along with a wide selection of sounds from the acclaimed PC3 and KORE 64™ expansion |
| User Programs: |
256 |
| Factory Multis: |
128 factory-crafted Multis – featuring up to 4 independent zones |
| User Multis: |
256 |
| General MIDI: |
No |
| Master EQ Section: |
Dedicated front-panel 3-band EQ with on/off switch |
| Effects: |
• Over 1000 complex effect chains, incorporated into programs featuring our award winning effects – reverbs, delays, chorus, flange, phaser, EQs, distortions, rotary speaker simulators, compressors, and more
• 16 total FX units
(chains can not be edited, but a chain can be selected in Multi Mode) |
| Controllers: |
• Front panel-mounted pitch and mod wheel
• 4 sliders
• 2 programmable switch buttons
• 2 Dedicated transpose switches
• 2 switch pedal inputs** (1 switch/sustain pedal is included)
• 1 continuous control pedal input
(** Each switch pedal input supports a single or dual switch pedal, or a single half-damper* pedal. Half-damper for MIDI output only.) |
| Analog Outputs: |
• Two 1/4″ balanced TRS analog (24-bit DACs)
• 21dBu maximum output
• 400Ω balanced source impedance |
| Audio Inputs: |
One stereo 1/8″ back-panel input for connecting your favorite MP3 player or other audio source for accompaniment playback |
| Headphones: |
• 1 rear panel 1/4″ headphone output
• 130mW into 32 ohm headphones |
| MIDI: |
In, Out |
| USB: |
• Complete MIDI functionality over USB
• User program/multi file transfer to/from PC/Mac/Flash Drive
• Operating System updates from PC/Mac/Flash Drive |
| FREE OS Updates: |
OS updates over USB and/or Flash Drive |
| Included Accessories: |
Power cable, Switch pedal, USB cable, (4) self adhesive feet |
| Height: |
(5.87″) (14.9cm) |
| Depth: |
(14.80″) (37.6cm) |
| Length: |
(50.63″) (128.6cm) |
| Weight: |
(38.6 lb.) (17.5 kg) |
| Power: |
External DC 15V 2.5A Power Supply |
